Fire-resistant door

Designed for both German and Chinese safety standard, the perfect combination of security and simplicity

Leaf thickness is 50mm, made of 1.0mm high-quality galvanized steel, flush sides.

Depending on the different fire-resistant classes, the infill of the door leaf can be aluminium silicate ceramic fibre or mineral wool, which fully glued to the steel sheet.

The standard frame thickness is 120mm, made of 1.5mm galvanized steel ,inserted with PVC sealing profile on the three sides.

High-quality fireproof stainless steel hinges,lock system and handles meet both functional and aesthetic requirements.

Finishes, dimensions, frame types and single/double-leaf etc can be customized according to the diversified needs.

Equipped with steel frame fire-resistant glazing and top light etc to meet specific needs

Model

FRD-A-S/D**

FRD-B-S/D**

FRD-C-S/D**

Fire-Insulated Time（min）

90

60

30

Leaf Thickness（mm）

60

60

60

Leaf Steel Thickness（mm）

1.0

1.0

1.0

Infill of the leaf

Fireproof board

Fireproof board

Fireproof board

Frame Depth（mm）

120

120

120

Frame Steel Thickness（mm）

1.5

1.5

1.5

Colors Finished

RAL Color and wooden surfaces /RAL
